Yasa Sets New Record with 42 kW/kg Power Density

Update on World Record Motor 42 kW/kg Power Density: Yasa Releases Update

2025-10-23 From Michael Richter | Translated by AI 2 min Reading Time

Related Vendors

Yasa already made headlines with the announcement of a new world record motor. Now the measurements have been confirmed: The drive, weighing only 12.7 kilograms (~28 pounds), achieves a peak power of 750 kilowatts (over 1,000 bhp), setting new standards in electric drive technology.

A symbol of engineering: The 59 kW/kg motor redefines efficiency.(Image: YASA Motors on LinkedIn) — A symbol of engineering: The 59 kW/kg motor redefines efficiency.
(Image: YASA Motors on LinkedIn)

An electric motor with over 1,000 hp, held in a single hand. What was considered unrealistic just a few years ago is now a reality. British electric motor specialist Yasa has unveiled a new unit that achieves a peak output of 750 kilowatts (over 1,000 bhp) while weighing only 12.7 kilograms (~28.0 pounds). This sets a new benchmark for power density and efficiency in electric drive technology.

World Record in Power Density

The new unit achieves a power density of 59 kW per kilogram, an increase of approximately 40 percent over Yasa's previous best of 42 kW/kg. For comparison: this is 2.5 times more than the best currently available radial machines and about six times more than typical drives in modern high-performance electric vehicles, which usually range from 5 to 15 kW/kg.

Example image: Dual-motor front e-axle – central component of the new high-performance e-drive technology from YASA and Automobili Lamborghini. (Image: YASA Limited)

This moves Mercedes-Benz subsidiary Yasa's boundaries of electric drive technology another significant step forward. Particularly noteworthy: the motor's continuous output is approximately 500 bhp, demonstrating that this is not a short-term performance peak but a technically robust design.

Two Decades of Technological Leap

Within just 20 years, Yasa has increased the power density of its electric motors by a factor of 50. This development makes the company one of the most innovative providers of compact, axial flux-based drives. The current generation thus represents the preliminary culmination of continuous optimization of magnetics, cooling, and mechanical design.

Technical Specifications

Voltage: 820 V DC
Current: 940 A RMS
Weight: 12.7 kg / 28 pounds (including housing, rotor, shaft)
Operating temperature (start): approx. 50 °C (~122 °F)

This combination of high voltage and current allows for enormous torque and an unprecedented power density in an extremely compact format.

A Look into the Future

Yasa still left it unclear for which specific application the new world record motor was developed, but hinted that it is a particularly demanding project. Industry observers suspect its use in high-performance areas, such as electric supercars, aerospace applications, or specialized vehicles.

What is certain: With this development, YASA not only delivers a technological milestone but also a preview of the future of high-performance electric drives – more compact, efficient, and powerful than ever before. (mr)
