Additive Manufacturing in HF Technology 3D-Printed Metacrystals Solve the Range Problem With 6G

Related Vendors

Taiwan Machine Tool & Accessory Builders' Association (TMBA)

SIMTOS (Seoul International Machine Tool Show)

The next generation of 6G mobile communications promises terabit data rates, but struggles with massive path losses in the sub-THz spectrum. Researchers have now presented a solution based on additively manufactured metacrystals that enables highly efficient beamforming directly via the material geometry. Energy-intensive phase controllers in RF front-ends are no longer necessary.

The development of 6G hardware is like a race against physics. In order to make bandwidths in the terahertz range from 100 GHz to 3 THz usable, engineers have to bundle signals extremely precisely (beamforming) to compensate for the enormous atmospheric attenuation.

Previous approaches have relied on massive phase array antennas. The problem: at sub-THz frequencies, these require hundreds of active components, which not only increase system complexity but also leave a massive thermal footprint on the PCB. A new approach by researchers at Aalto University in Finland now relies on metacrystals that are produced using high-precision additive manufacturing.

Shaft Control Through Topology

Metacrystals are artificially created structures whose electromagnetic properties are not determined by their chemical composition but by their geometric arrangement. They act as so-called topological insulators for electromagnetic waves.

Band gaps are created by a specific, periodic lattice structure within the crystal. Waves can only propagate along defined paths or at the edges of the structure. This occurs almost loss-free. For the 6G design, this means that beam shaping occurs passively through the structure of the material itself, rather than through electronic phase shifting in the circuit.

Additive Manufacturing As A Technological Enabler

The decisive breakthrough lies in manufacturing. The structures required for sub-THz applications are so complex that traditional subtractive processes (milling) or conventional etching processes fail. This is where additive manufacturing comes into its own:

• Geometric freedom: 3D printing allows the realization of cavity structures and complex lattice networks in the micrometer range, which are essential for the manipulation of millimeter waves.
• Material gradients: Modern multi-material printers can combine different dielectrics within a component in order to precisely control the refractive index locally.
• Rapid RF prototyping: RF developers can iterate antenna designs and waveguides within hours, shortening development cycles for 6G components.

System Benefits for the HF Front End

For the system designer, the use of printed metacrystals offers advantages over classic semiconductor-based solutions:

• Energy efficiency: Since the beam is controlled passively via the material geometry, the power requirement of the HF front end is significantly reduced.
• Thermal management: Fewer active components mean less waste heat—a critical factor when integrating 6G modules into compact end devices or small cells.
• Integration: The 3D-printed structures can be placed directly on the RFIC (Radio Frequency Integrated Circuit), which minimizes the size of the housing.

The combination of topological physics and additive manufacturing could pave the way for the commercialization of 6G. While the semiconductor industry is still working on efficient THz transistors, additive manufacturing already offers the tools to master the medium for these waves. For electronics production, this means 3D printing is moving from housing construction directly into the heart of the high-frequency circuit. (heh)
