Vapor-Cooled Microchannels An Embedded 3D Microchannel System for Better Cooling of High-Performance Chips

Related Vendors

dataTec AG

Taiwan Machine Tool & Accessory Builders' Association (TMBA)

Wuxi InfiMotion Technology Co., Ltd.

A Japanese research team has developed a novel 3D microchannel structure for chip cooling. By embedding microchannels, the cooling efficiency of chips is dramatically increased using the evaporative heat of water.

The miniaturization of semiconductors and the trend towards ever more powerful processors present the electronics industry with a central challenge: thermal management. Conventional cooling systems reach their limits in dissipating heat, as more and more heat needs to be removed from increasingly smaller areas. Now, researchers at the University of Tokyo have achieved a breakthrough that could fundamentally address this issue.

At the center of their innovation is a newly developed 3D microchannel structure that directs water through tiny capillaries within the chip. Unlike classical cooling methods, this system not only uses the increase in water temperature (sensible heat) but primarily its phase change—evaporation—to efficiently remove energy. Water can absorb about seven times more heat during the transition from liquid to vapor than with a mere temperature increase, massively enhancing the cooling efficiency.

Water Vapor in Microchannels for Targeted Heat Dissipation

The researchers integrated complex capillary microchannels directly into the chip structure and combined them with an intelligent distributor design. Initially, the water is supplied via large distributor channels and then directed through narrow microchannels that lie directly at the hotspots of the electronics. After absorbing the heat, the water evaporates and is removed via a second distributor channel.

One of the biggest challenges with this two-phase cooling is managing the resulting vapor within the narrow structures. However, by precisely adjusting the channel geometries and flow management, the researchers were able to create stable conditions that allow for continuous and low-loss cooling. The thermal efficiency, measured by the Coefficient of Performance (COP), reached values of up to 100,000 in experiments—a level that exceeds conventional cooling systems by several orders of magnitude. The researchers mention in their study a heat energy transfer up to 7 times greater.

Special attention in the development was given to the interplay between microchannel design and distributor architecture. In comparative studies, various geometries were tested, showing that both the width and depth of the microchannels, as well as the structure of the distributors, significantly influence performance. Through optimized control of the coolant flow, the researchers were able to efficiently address local hotspots, which are particularly critical in AI chips and GPUs.

Moreover, the technology offers additional advantages: it enables more compact cooling concepts that require less installation space and opens up possibilities for passive cooling. In some configurations, heat transport could occur solely through natural convection and phase change, without the need for external pumping systems. This would not only improve energy efficiency but also reduce system complexity and costs.

Potential applications extend far beyond the traditional semiconductor field. Use in lasers, optical sensors, LED systems, as well as in aerospace technology, where efficient thermal management in constrained spaces is particularly in demand, is conceivable. New possibilities could also arise for automotive power electronics.

"Efficient cooling is crucial for the next generation of high-performance electronics," emphasizes Professor Masahiro Nomura from the Institute of Industrial Science at the University of Tokyo. "Our technology could be the key to making future system designs not only more powerful but also more sustainable." The complete results were recently published in the journal Cell Reports Physical Science (DOI: 10.1016/j.xcrp.2025.102520). (sg)
