Organic solar cells have so far failed due to unstable p/n junctions. Researchers at Osaka Metropolitan University have now developed a molecule that organizes itself and forms controllable structures.

In photovoltaic research, organic solar cells have been considered one of the most promising alternatives to established silicon technology for years. They promise flexible, lightweight energy solutions that can be produced cost-effectively and integrated into completely new areas of application. These range from bendable displays to textile solar cells. However, despite decades of research, their breakthrough failed to materialize because their practical implementation was plagued by fundamental problems.

Scientists at Osaka Metropolitan University have now discovered that the problem lay not in the materials used, but in a fundamental design flaw. Their research, published in the renowned journal "Angewandte Chemie International Edition", shows that organic solar cells have simply been built incorrectly up to now. The traditional approach led to unstable and difficult-to-reproduce manufacturing processes that prevented commercial use.

Unstable Interfaces And Fluctuating Performance

The basic problem lay in the generation of the p/n junctions, which are necessary for the conversion of sunlight into electrical energy. Until now, the decisive structures have been produced according to the so-called bulk heterojunction principle: The two different types of material, p-type and n-type, are physically mixed together to create as many contact points as possible.

However, the process proved to be a fundamental weakness. Even the slightest changes to the production conditions led to completely different results. If, for example, the processing temperature fluctuated slightly, a different solvent was used or the drying time changed, uncontrollable mixtures with chaotic structures were created. The result was unstable interfaces and fluctuating performance. This means that reliable mass production is not possible.

Paradigm Shift Through Molecular Self-Organization

The researchers led by Takeshi Maeda from Osaka Metropolitan University have taken a new approach: instead of mixing two different materials, they use a single molecule called TISQ, which organizes itself and forms nanoscale p/n junctions. This bottom-up approach enables controllable and reproducible structures in organic solar cells for the first time.

The control of the molecular arrangement by different solvents is remarkable. Polar solvents produce J-type aggregates, which enable higher photocurrents, while non-polar solvents form H-type aggregates. This precise control option was not available with conventional mixing systems and opens up completely new avenues in solar cell development.

Potential for the Electronics Industry

The technology dispels the widespread misconception that organic solar cells are fundamentally inefficient due to their materials. In fact, the problem lay in the lack of precision in charge separation and charge transport, which were hindered by the chaotic mixed structures.

Although the first prototypes still show low efficiency values, the concept proves its fundamental functionality. The self-organization of the TISQ molecule makes it possible to retain the typical advantages of organic solar cells, such as flexibility, low weight and printability, while at the same time significantly improving stability and reproducibility.

For the electronics industry, this approach opens up new possibilities for energy-autonomous sensor systems in the Internet of Things, wearable electronics with integrated energy supply and flexible displays with self-powered properties. The potential for building-integrated photovoltaics in smart buildings, where the combination of efficiency and processability is crucial, is particularly interesting.

Outlook for Industrial Applications

The research results mark an important milestone in organic photovoltaics. The new approach could lead to stable, scalable organic solar cells in the medium term, which for the first time translate the theoretical potential of this technology into practical applications.

The decisive factor for decision-makers in the electronics industry will be how quickly this basic research can be transferred to industrial production processes. The controlled self-organization of the TISQ molecule promises significantly more reproducible manufacturing processes than previous approaches and could therefore pave the way for the commercial use of organic solar cells. (heh)
