Wi-Fi 7, the latest advancement in wireless network technology, is also set to enhance industrial connectivity. What is the technical background? And what does the new standard bring for WLAN connections?

Wi-Fi 7 is the next evolutionary stage of the WLAN standard and is expected to offer more speed, capacity, and efficiency compared to its predecessors.(Image: Smile Studio AP - stock.adobe.com) — Wi-Fi 7 is the next evolutionary stage of the WLAN standard and is expected to offer more speed, capacity, and efficiency compared to its predecessors.
(Image: Smile Studio AP - stock.adobe.com)

Although there are differences: In German language usage, the terms WLAN and Wi-Fi are often used synonymously. That's not fundamentally wrong. Because in an international context, the term Wireless Local Area Network, or WLAN, is simply not so common. Here, people talk about Wi-Fi. The abbreviation stands for Wireless Fidelity.

To be precise, the latter refers more to a company consortium or a brand name. The former is the so-called Wi-Fi Alliance, which certifies WLAN devices. The brand name is used for WLAN devices and networks that are based on corresponding industry standards of the Institute of Electrical and Electronics Engineers (IEEE).

What is Wi-Fi 7 and how does it differ from previous Wi-Fi standards?

Wi-Fi 7 is thus the next generation of the WLAN standard, following on from Wi-Fi 6 (IEEE 802.11ax). With data transfer rates of up to 30 Gbps, it promises significant improvements in speed, capacity, and efficiency compared to its predecessors. It is based on the IEEE standard 802.11be.

Behind this are techniques such as Multi-User Multiple Input Multiple Output (MU-MIMO), Multi-User Orthogonal Frequency Division Multiple Access (MU-OFDMA). However, both of these are already known from Wi-Fi 6. The new standard also operates over the three frequency bands 2.4 GHz, 5 GHz and 6 GHz.

New, for example, is a technique called Multi Link Operation (MLO). This makes it possible for a device to use multiple frequency bands simultaneously. Channels that allow transmissions with 320 MHz provide the higher speed.

If a large resource unit is required due to throughput requirements, this large bandwidth may not be available across the entire channel bandwidth. This is where the principle of the Multi Resource Unit (MRU) comes into play. With a concept comparable to MLO, but on the same channel, two resource units—contiguous or non-contiguous—can be aggregated for a single user. This is how you achieve the necessary throughput.

MLO and MRU are supported by the accelerated Quadrature Amplitude Modulation. With 4K QAM, each signal can contain a larger amount of data, compared to 1K QAM under Wi-Fi 6E, the current standard Wi-Fi.

What are the main features and improvements of Wi-Fi 7?

The WLAN connections working with the new standard show some changes compared to the 6-Ghz band of Wi-Fi 6. Not only industrial applications benefit from the transmission rate with more gigabits per second. In the private sector, it is useful for example in online gaming or the connection of smart home devices. Here are the key features and improvements summarized at a glance:

Higher data rates: The new standard is expected to achieve data rates of up to 30 Gbit/s. This makes it predestined for bandwidth-intensive industrial applications.
Increased capacity: The use of MU-MIMO and OFDMA allows the simultaneous use of multiple connections and devices. This optimizes network efficiency in crowded industrial environments.
Lower latency times: Wi-Fi 7 also reduces latency times. This favors faster response times in time-critical industrial processes.
Greater reliability: Thanks to techniques such as spatial frequency reuse, reliability also benefits in Wi-Fi 7 networks. Corresponding networks are characterized by fewer packet losses and signal interference.

Wi-Fi 7: What about interference and reliability in industrial environments?

Wi-Fi 7 uses advanced techniques like spatial frequency reuse and beamforming. This is intended to reduce interference on one hand. On the other hand, both can improve signal reliability in industrial environments. These technologies ensure a more efficient use of the wireless spectrum. And also better adaptability to changing environmental conditions becomes possible.

How can industrial applications benefit from Wi-Fi 7?

Based on the technical specifications, Wi-Fi 7 offers several advantages for industrial applications. This includes increased productivity. Faster and more reliable wireless connectivity enables real-time monitoring, control, and optimization of industrial processes.

Also, corresponding networks offer comparatively more flexibility. Wi-Fi 7 supports mobility within industrial facilities, so that employees can access important data and applications from anywhere on the premises. Especially here, the higher reliability is a decisive factor.

Subscribe to the newsletter now

Don't Miss out on Our Best Content

Business E-mail

Please enter a valid mailadress.

By clicking on „Subscribe to Newsletter“ I agree to the processing and use of my data according to the consent form (please expand for details) and accept the Terms of Use. For more information, please see our Privacy Policy. The consent declaration relates, among other things, to the sending of editorial newsletters by email and to data matching for marketing purposes with selected advertising partners (e.g., LinkedIn, Google, Meta)

Date: 08.12.2025

Naturally, we always handle your personal data responsibly. Any personal data we receive from you is processed in accordance with applicable data protection legislation. For detailed information please see our privacy policy.

Consent to the use of data for promotional purposes

I hereby consent to Vogel Communications Group GmbH & Co. KG, Max-Planck-Str. 7-9, 97082 Würzburg including any affiliated companies according to §§ 15 et seq. AktG (hereafter: Vogel Communications Group) using my e-mail address to send editorial newsletters. A list of all affiliated companies can be found here

Newsletter content may include all products and services of any companies mentioned above, including for example specialist journals and books, events and fairs as well as event-related products and services, print and digital media offers and services such as additional (editorial) newsletters, raffles, lead campaigns, market research both online and offline, specialist webportals and e-learning offers. In case my personal telephone number has also been collected, it may be used for offers of aforementioned products, for services of the companies mentioned above, and market research purposes.

Additionally, my consent also includes the processing of my email address and telephone number for data matching for marketing purposes with select advertising partners such as LinkedIn, Google, and Meta. For this, Vogel Communications Group may transmit said data in hashed form to the advertising partners who then use said data to determine whether I am also a member of the mentioned advertising partner portals. Vogel Communications Group uses this feature for the purposes of re-targeting (up-selling, cross-selling, and customer loyalty), generating so-called look-alike audiences for acquisition of new customers, and as basis for exclusion for on-going advertising campaigns. Further information can be found in section “data matching for marketing purposes”.

In case I access protected data on Internet portals of Vogel Communications Group including any affiliated companies according to §§ 15 et seq. AktG, I need to provide further data in order to register for the access to such content. In return for this free access to editorial content, my data may be used in accordance with this consent for the purposes stated here. This does not apply to data matching for marketing purposes.

Right of revocation

I understand that I can revoke my consent at will. My revocation does not change the lawfulness of data processing that was conducted based on my consent leading up to my revocation. One option to declare my revocation is to use the contact form found at https://contact.vogel.de. In case I no longer wish to receive certain newsletters, I have subscribed to, I can also click on the unsubscribe link included at the end of a newsletter. Further information regarding my right of revocation and the implementation of it as well as the consequences of my revocation can be found in the data protection declaration, section editorial newsletter.

The increase in capacity and efficiency is also ideal for IoT devices. More and more devices, which are used in industrial automation and monitoring applications, are to communicate with each other via the Internet of Things. Wi-Fi 7 creates the conditions for this.

Thus, Wi-Fi 7 provides the high-speed and low-latency connectivity required for applications of Industry 4.0 or IoT. This pays off when integrating sensors, actuators and other IoT devices into industrial processes. After all, it facilitates the collection and analysis of large amounts of data. And applications such as predictive maintenance, working with VR glasses, or asset tracking also benefit from the advantages.

How can industrial companies prepare for the transition to Wi-Fi 7?

At the CES 2024 trade fair, the Wi-Fi Alliance officially launched the new WLAN standard. Industrial companies can prepare for the transition to Wi-Fi 7 by having those responsible first assess the current network infrastructure. In this process, areas for improvement or upgrading need to be identified.

It is also advisable to plan for possible interruptions during the transition phase. This also involves implementing measures to minimize downtime. And of course, it also requires compatible hardware, i.e., both routers and access points that support the new technology.

People should not be forgotten amidst all the technology. Where it seems sensible, investments in training and education of staff could be worthwhile. Moreover, it can be advantageous to already discuss cooperations with technology providers and service providers in order to develop tailor-made solutions for one's own use cases.
