The press manufacturer Dieffenbacher has developed a series of particularly efficient, economical, and flexibly configurable hydraulic presses. The modular industrial hydraulics from Bosch Rexroth contributed to meeting the requirements for minimal energy consumption.

Modularly economical, internationally competitive: Using largely standardized components, the manufacturer Dieffenbacher realizes a comprehensive series of hydraulic presses for sheet metal forming as well as shaping plastics and laminated wood.(Image: Bosch Rexroth) — Modularly economical, internationally competitive: Using largely standardized components, the manufacturer Dieffenbacher realizes a comprehensive series of hydraulic presses for sheet metal forming as well as shaping plastics and laminated wood.
(Image: Bosch Rexroth)

To form sheet metal as well as to shape glass-fiber-reinforced plastics and layered wood materials, the medium-sized family-owned company Dieffenbacher GmbH, Eppingen, has developed a series of hydraulic presses. This series includes variants with pressing forces ranging from 1000 kN to 10,000 kN. To manufacture the presses economically and remain competitive internationally, the specialists at Dieffenbacher consistently use modular components, particularly in the drive technology.

Together towards a modular drive concept

Georg Obermaier, head of the Business Unit Forming, explains the concept of the so-called Tailored Press from Dieffenbacher: "We wanted to build a future-ready press from standard modules that can be individually adjusted in terms of force, installation space, table size, and ram size. At the same time, we set high standards for energy efficiency. We found both aspects met with our system partner Bosch Rexroth, with whom we designed a modular drive concept that they ultimately were able to produce for us."

Gallery

Minimized energy consumption: Speed-controlled drives and demand-driven control of drive power from Bosch Rexroth are key components of the forward-looking concept for hydraulic presses.(Image: Bosch Rexroth)

Economical, flexible, and maintenance-friendly: The digitized hydraulic drive system from Bosch Rexroth, in conjunction with an accumulator control and hydraulic accumulators, requires only about 30 percent of the energy previously customary.(Image: Bosch Rexroth)

The modular drive concept enables the machine builder to easily implement the Tailored Press in various performance and speed classes. For instance, a version with 5000 kN press force can be simply converted to a speed variant with active high-speed parallelism for precise component thicknesses and higher component quality by changing to a different pump variant. For the entire range of press performance, Bosch Rexroth has suitable pump variants available. This ensures streamlined processes throughout the entire lifecycle of the presses, from engineering and inventory management to service. Additionally, other variants of presses, for example with drawing cushions, can be quickly realized as needed through the modular construction system of the drive technology.

Largely standardized

The drive modules for the current series of presses should consist of standard components as much as possible, aligning with the overall concept. For this purpose, the experts from Bosch Rexroth were able to provide their concept for the speed-controlled Power-on-Demand drive, innovative pump technology, and comprehensive know-how for installation and commissioning. Georg Obermaier comments, "Bosch Rexroth has an excellent reputation worldwide in the press industry. The company stands for continuity and good advice." Furthermore, Bosch Rexroth has a production facility for drive technology in Brno, Czech Republic, which is regionally close to the press manufacturer's operations.

Demand-oriented flow rates

For the main drive, press manufacturers use their modular concept axial piston variable pumps A4VSO in various nominal sizes with digital control device HS5, and the press module IH04 with a standardized safety concept and EC type-examination certificate for Performance Level e Category 4 according to the requirements of DIN EN ISO 16092-3 and DIN EN 289.

Control and cooling circuits with water cooling are constructed from functionally equipped manifold plates and motor-pump units with axial piston variable pumps A10VSO. Bosch Rexroth provides the speed-controlled hydraulic unit corresponding to the respective press design as a component of a complete package.

The electro-hydraulic drive concept generates volume flows as needed. This is achieved through the swivel angle of the axial pumps and the motor speed. The pumps can operate at 1.5 times the power when needed. A digital control system precisely adjusts the volume flows to specific process points. When no power is required, the pumps are turned off. At these times, the presses require virtually no energy.

70 percent less energy

Compared to conventional drives that operate at constant speeds, the optimally controlled electro-hydraulic press drives require only about half the energy. Together with adaptive accumulator control, the energy requirement can be reduced to about only 30 percent. The directly driven hydraulic presses automatically adjust the charging pressure of the hydraulic accumulator in anticipation of upcoming forming processes. For the operating personnel, familiar workflows and processes are retained. Forces, paths, and ram parameters are set as before, with the respective speeds automatically calculated by the drive control.

Digitalization simplifies service

Also in terms of advancing digitalization, the innovative drive concept proves to be advantageous. Thanks to integrated interfaces, the press manufacturer can equip particularly economical machines with its digitalization platform, Evoris. This enables the integration of cutting-edge online services even in the individually customized presses of the current series. This includes remote maintenance, condition monitoring, and data-based analyses for process improvements and predictive maintenance. Thus, the manufacturer simplifies and accelerates its global service, which in turn benefits users as they can minimize downtime and optimize the use of the presses.

Subscribe to the newsletter now

Don't Miss out on Our Best Content

Business E-mail

Please enter a valid mailadress.

By clicking on „Subscribe to Newsletter“ I agree to the processing and use of my data according to the consent form (please expand for details) and accept the Terms of Use. For more information, please see our Privacy Policy. The consent declaration relates, among other things, to the sending of editorial newsletters by email and to data matching for marketing purposes with selected advertising partners (e.g., LinkedIn, Google, Meta)

Date: 08.12.2025

Naturally, we always handle your personal data responsibly. Any personal data we receive from you is processed in accordance with applicable data protection legislation. For detailed information please see our privacy policy.

Consent to the use of data for promotional purposes

I hereby consent to Vogel Communications Group GmbH & Co. KG, Max-Planck-Str. 7-9, 97082 Würzburg including any affiliated companies according to §§ 15 et seq. AktG (hereafter: Vogel Communications Group) using my e-mail address to send editorial newsletters. A list of all affiliated companies can be found here

Newsletter content may include all products and services of any companies mentioned above, including for example specialist journals and books, events and fairs as well as event-related products and services, print and digital media offers and services such as additional (editorial) newsletters, raffles, lead campaigns, market research both online and offline, specialist webportals and e-learning offers. In case my personal telephone number has also been collected, it may be used for offers of aforementioned products, for services of the companies mentioned above, and market research purposes.

Additionally, my consent also includes the processing of my email address and telephone number for data matching for marketing purposes with select advertising partners such as LinkedIn, Google, and Meta. For this, Vogel Communications Group may transmit said data in hashed form to the advertising partners who then use said data to determine whether I am also a member of the mentioned advertising partner portals. Vogel Communications Group uses this feature for the purposes of re-targeting (up-selling, cross-selling, and customer loyalty), generating so-called look-alike audiences for acquisition of new customers, and as basis for exclusion for on-going advertising campaigns. Further information can be found in section “data matching for marketing purposes”.

In case I access protected data on Internet portals of Vogel Communications Group including any affiliated companies according to §§ 15 et seq. AktG, I need to provide further data in order to register for the access to such content. In return for this free access to editorial content, my data may be used in accordance with this consent for the purposes stated here. This does not apply to data matching for marketing purposes.

Right of revocation

I understand that I can revoke my consent at will. My revocation does not change the lawfulness of data processing that was conducted based on my consent leading up to my revocation. One option to declare my revocation is to use the contact form found at https://contact.vogel.de. In case I no longer wish to receive certain newsletters, I have subscribed to, I can also click on the unsubscribe link included at the end of a newsletter. Further information regarding my right of revocation and the implementation of it as well as the consequences of my revocation can be found in the data protection declaration, section editorial newsletter.

Economical, flexible, and quiet

As Georg Obermaier reports, the partnership with the drive technicians from Bosch Rexroth is an important step towards standardization, flexibility, and economic efficiency. "In addition to energy efficiency and digitalization, the drive technology also impresses in terms of compact construction and noise emission. Our requirement of a maximum 80 dbA sound pressure was significantly undercut with an actual 70 dbA."
